Our innovative ZEEROV (Zero Emission Electric ROV) is a full - electric work - class ROV with an outstanding power management system. It can achieve stronger power and better manoeuvrability within the same size as the successful SUPPORTER ROV.
The ROV technology of ZEEROV is derived from years of practical operation experience of our engineers. This product is designed with a high emphasis on reliability and flexibility, which are the key success factors for achieving long - term underwater operations and effective remote control from the shore.
lFeatures
1. Abundant Interfaces and Safety Assurance: ZEEROV is equipped with up to 49 electrical connectors for connecting external devices such as manipulators, tooling, survey sensors, and cameras. All power supplies are monitored for ground faults.
2. Diverse Intelligent Control Functions: The ROV control system supports multiple automatic functions like AutoPOS and AutoTRACK. It can also achieve over - the - horizon control through an onshore Remote Operation Center (ROC).
lTechnical Specifications
| Parameter | Details |
| Dimensions(L/W/H) | 2.75m/1.7m/1.69 m |
| Weight | 3800 kg |
| Payload | 600 kg |
| Through Frame Lift | 1500 kg |
| Depth Rating | 2000 m(Optional 3000 m,4000 m,and 5000 m) |
| Designed Submersion Duration | 30 days |
| Thrusters | 7xKD-300 thrusters,800VDC;Each thruster can outpu 16kW continuously simultaneously,with a rated power 20kW,can be isolated individually,and has a peak power of approximately 30kW |
| Bollard Pull(Calculated from Thruster Pool Test) | Forward:1226 kg;Aft:1218 kg;Lateral:1120 kg;Vertical UP:1169 kg;Vertical DOWN:1238 kg |
